Tubing, Stainless Steel, 0.083 inch (2.10 mm) ID, 1/8 (3.20 mm) OD, Your custom continuous length tubing, priced per meter, ARE-Applied Research brand.
Additional Information:
ARE-Applied Research HPLC Grade Stainless Steel tubing is manufactured from high-purity 316L stainless steel and is designed for demanding high-pressure liquid chromatography applications. Welded and annealed for consistent performance, this tubing is manufactured and tested according to EN 10217-7 standards, providing the strength, dimensional accuracy, and reliability required for modern analytical laboratories.
49408-COIL-1C allows laboratories to order a custom continuous length of 316L stainless steel tubing with a 0.083 inch (2.10 mm) internal diameter and a 1/8 inch (3.20 mm) outer diameter. This Special Order Item is priced per meter, enabling users to specify the exact tubing length required for preparative chromatography systems, custom fluid pathways, process-scale applications, and specialized laboratory installations. The large internal diameter supports higher flow rates and larger fluid volumes while minimizing flow restriction.
The corrosion-resistant 316L stainless steel construction provides excellent compatibility with a wide range of chromatography solvents and mobile phases while delivering exceptional mechanical strength. With a maximum pressure rating of 24,000 psi (1654 bar) and a maximum operating temperature of 400°C, this tubing is suitable for demanding high-pressure laboratory and preparative chromatography environments.
Key Benefits
Custom continuous length tubing
HPLC-grade 316L stainless steel construction
Manufactured and tested to EN 10217-7 standards
Large internal diameter for high-flow applications
Maximum pressure rating of 24,000 psi (1654 bar)
Excellent corrosion resistance
Suitable for preparative and process-scale fluid pathways
High temperature resistance up to 400°C
Typical Applications
Preparative HPLC systems
High-flow fluid transfer
Solvent delivery systems
Bulk mobile phase transport
Process chromatography
Analytical instrumentation
Laboratory fluid handling
Custom high-pressure fluid paths
Specifications
Product Type: Stainless Steel Tubing
Material: 316L Stainless Steel
Internal Diameter: 0.083 in. (2.10 mm)
Outer Diameter: 1/8 in. (3.20 mm)
Length: Continuous Length
Pricing Basis: Per Meter
Maximum Pressure: 24,000 psi (1654 bar)
Maximum Temperature: 400°C
Manufacturing Standard: EN 10217-7
Dimensional Tolerance: ±0.05 mm
Brand: ARE-Applied Research
Resources
Special Order Item Information
This item is supplied in the length specified at the time of order.
Special Order Items cannot be canceled or returned once an order has been placed.
Custom lengths are available to meet specific application requirements.
Important Notes
Special Order Item
Continuous length tubing priced per meter
Designed for HPLC and high-pressure laboratory applications
Large-bore tubing supports high flow rates
Manufactured from corrosion-resistant 316L stainless steel
Maximum pressure rating of 24,000 psi
Maximum operating temperature of 400°C
Precision dimensional tolerances of ±0.05 mm
