Tubing, Stainless Steel, 0.010 inch (0.25 mm) ID, 1/32 inch (0.79 mm) OD, Your custom continuous length tubing, priced per meter, ARE-Applied Research brand.
Additional Information:
ARE-Applied Research HPLC Grade Stainless Steel tubing is manufactured from high-purity 316L stainless steel and is designed for demanding high-pressure liquid chromatography applications. Welded and annealed for consistent performance, this tubing is manufactured and tested according to EN 10217-7 standards, providing the strength, dimensional accuracy, and reliability required for modern analytical laboratories.
49401-COIL-1C allows laboratories to order a custom continuous length of 316L stainless steel tubing with a 0.010 inch (0.25 mm) internal diameter and a 1/32 inch (0.79 mm) outer diameter. This Special Order Item is priced per meter, enabling users to specify the exact tubing length required for system builds, repairs, custom flow paths, and specialized chromatography configurations.
The narrow internal diameter helps minimize system volume and reduce band broadening, making it ideal for HPLC and UHPLC applications where chromatographic efficiency is critical. The corrosion-resistant 316L stainless steel construction provides excellent compatibility with a wide range of mobile phases while offering outstanding mechanical strength and temperature stability up to 400°C.
Key Benefits
Custom continuous length tubing
HPLC-grade 316L stainless steel construction
Manufactured and tested to EN 10217-7 standards
High-pressure capability for chromatography applications
Low internal volume design
Excellent corrosion resistance
Suitable for custom fluid pathways
High temperature resistance up to 400°C
Typical Applications
HPLC systems
UHPLC systems
High-pressure fluid transfer
Analytical instrumentation
Custom chromatography configurations
Sample delivery lines
Detector connections
Laboratory fluid pathways
Specifications
Product Type: Stainless Steel Tubing
Material: 316L Stainless Steel
Internal Diameter: 0.010 in. (0.25 mm)
Outer Diameter: 1/32 in. (0.79 mm)
Length: Continuous Length
Pricing Basis: Per Meter
Maximum Temperature: 400°C
Manufacturing Standard: EN 10217-7
Dimensional Tolerance: ±0.05 mm
Brand: ARE-Applied Research
Resources
Special Order Item Information
This item is supplied in the length specified at the time of order.
Special Order Items cannot be canceled or returned once an order has been placed.
Custom lengths are available to meet specific application requirements.
Important Notes
Special Order Item
Continuous length tubing priced per meter
Designed for HPLC and high-pressure laboratory applications
Welded and annealed stainless steel construction
Manufactured from corrosion-resistant 316L stainless steel
Narrow internal diameter helps minimize system volume
Maximum operating temperature of 400°C
Precision dimensional tolerances of ±0.05 mm
