Column Filters, for HPLC, 2.0 um Stainless Steel filter element and All-PEEK body. Disposable, with end plugs. Natural. Cogent Brand. 5/PK.
Additional Info:
The Cogent In‑Line Column Filter (2.0 µm) is a disposable pre‑column protection device designed to protect analytical HPLC columns from larger particulate contamination while maintaining lower pressure impact compared to finer‑pore filters. This configuration is commonly selected when sample matrices are cleaner or when methods are sensitive to additional restriction.
Each filter incorporates a 2.0 µm stainless steel filter element housed in a natural‑color all‑PEEK body, providing excellent chemical compatibility and a metal‑free flow path outside the filter element itself. These filters effectively trap undissolved particles and pump‑seal debris, helping prevent irreversible column damage and premature performance loss.
The universal connection design fits all standard analytical HPLC column threads and pilot lengths. Installation is straightforward using hand tightening or a wrench, allowing fast replacement during routine maintenance or method setup.
Key Features
Effective Pre‑Column Protection
Prevents particulates from entering the analytical column
Reduces risk of frit blockage and column damage
Supports longer column life in routine workflows
2.0 µm Stainless Steel Filter Element
Suitable for applications requiring lower flow restriction
Balanced protection for cleaner samples
Minimizes added system backpressure
All‑PEEK Disposable Housing
Broad chemical compatibility
Lightweight, corrosion‑resistant construction
Disposable design eliminates cleaning or regeneration
Universal HPLC Connection
Fits all analytical HPLC column threads and pilot lengths
Compatible with standard wrenching or hand‑tight installation
Easily integrated into existing chromatographic systems
Usage & Replacement Guidance
When an in‑line column filter is installed, system backpressure should be monitored. A gradual increase in pressure typically indicates filter loading.
To replace:
Reduce system pressure to atmospheric
Disconnect the used filter
Dispose of the unit
Install a new in‑line filter and resume operation
These devices are commonly referred to as pre‑column filters because they are installed upstream of the analytical column.
Pressure Rating & Compatibility
Maximum pressure: 4,500 psi
Compatible with: Analytical HPLC systems
Not recommended for: UHPLC pressure ranges
For higher particulate retention, a 0.5 µm version is available within the same filter family.
Typical Applications
Routine analytical HPLC
Cleaner sample matrices
Method development and validation
Column life‑extension programs
Systems sensitive to pressure increases
