Beta Tool-2. For 1/16 or 1/8" Stainless Steel HPLC Tubing, Blue Grips. MICROSOLV Brand. 1 EA.
Additional Info:
The 46020‑BT Beta Tool‑2™ is a precision tubing pliers and straightening tool designed for laboratories working with 1/16" and 1/8" stainless steel HPLC tubing. This dual‑purpose tool is engineered to remove kinks, correct bends, and form smooth, controlled tubing curves, helping maintain optimal flow paths and system performance.
The tool incorporates two precision‑machined center holes, one slightly larger than 1/16" and the other slightly larger than 1/8", allowing tubing to be guided and reshaped without deformation. By applying controlled pressure, users can straighten damaged tubing or create consistent, seamless bends, reducing turbulence and minimizing dead volume inside the tubing.
Unlike conventional pliers, the Beta Tool‑2™ features a shortened, rounded nose design, enabling access to tight and hard‑to‑reach areas inside HPLC instruments, such as near injectors, valves, and detector connections. This makes it especially valuable for in‑place tubing adjustments without disassembly.
The tool also includes soft, ergonomic grip handles, providing improved control and reducing hand fatigue during routine maintenance.
Why Use a Tubing Straightener Tool?
Kinked or improperly bent tubing can lead to:
Restricted or turbulent flow
Increased system backpressure
Peak distortion and loss of resolution
Dead volume and reproducibility issues
The Beta Tool‑2™ helps maintain:
Smooth internal flow paths
Proper tubing geometry
Consistent chromatographic performance
Without cutting or replacing tubing unnecessarily.
Key Features
Dual‑Size Tubing Capability
Precision‑fit channels for 1/16" and 1/8" stainless steel tubing
Supports common HPLC system configurations
Straightening and Bending in One Tool
Removes kinks and bends
Forms smooth, controlled tubing curves
Maintains internal diameter integrity
Compact, Instrument‑Access Design
Short, rounded nose reaches confined instrument spaces
Ideal for work near injectors, valves, and detectors
Enables adjustments without removing installed tubing
Ergonomic and Easy to Use
Soft, blue comfort grips for secure handling
Reduces operator fatigue during maintenance work
Provides controlled, repeatable results
Typical Applications
Straightening kinked HPLC tubing
Forming precise bends for system setup
Adjusting tubing inside installed instrumentation
Routine HPLC system maintenance
Preventing flow path restrictions and dead volume
