Tubing, Stainless Steel, 0.180 inch (4.60 mm) ID, 1/4 inch (6.35 mm) OD, HPLC grade, 10 meter roll, ARE-Applied Research brand. 1 EA.
Additional Information:
ARE-Applied Research HPLC Grade Stainless Steel tubing is manufactured from high-purity 316L stainless steel and is designed for demanding high-pressure liquid chromatography applications. Welded and annealed for consistent performance, this tubing is manufactured and tested according to EN 10217-7 standards, providing the strength, dimensional accuracy, and reliability required for modern analytical laboratories.
49418-COIL-10M is supplied as a 10-meter continuous coil with a 0.180 inch (4.60 mm) internal diameter and a 1/4 inch (6.35 mm) outer diameter. The large internal diameter is ideal for preparative and process-scale chromatography applications that require high flow rates, greater fluid volumes, and minimal flow restriction. This tubing is well suited for preparative HPLC systems, solvent delivery applications, bulk fluid transfer, and custom high-flow laboratory fluid pathways.
The corrosion-resistant 316L stainless steel construction provides excellent compatibility with a wide range of solvents and chromatography mobile phases while delivering exceptional mechanical strength. With a maximum pressure rating of 21,000 psi (1447 bar) and a maximum operating temperature of 400°C, this tubing is suitable for demanding high-pressure laboratory and chromatography environments.
Key Benefits
HPLC-grade 316L stainless steel construction
Manufactured and tested to EN 10217-7 standards
Large-bore tubing for high-flow applications
Maximum pressure rating of 21,000 psi (1447 bar)
Excellent corrosion resistance
Suitable for preparative and process-scale fluid pathways
High temperature resistance up to 400°C
Durable welded and annealed construction
Typical Applications
Preparative HPLC systems
Process chromatography
High-flow solvent delivery systems
Bulk mobile phase transfer
Laboratory fluid handling
Custom high-pressure fluid pathways
Process development laboratories
Analytical and preparative instrumentation
Specifications
Product Type: Stainless Steel Tubing
Material: 316L Stainless Steel
Internal Diameter: 0.180 in. (4.60 mm)
Outer Diameter: 1/4 in. (6.35 mm)
Length: 10 Meters
Configuration: Continuous Coil
Maximum Pressure: 21,000 psi (1447 bar)
Maximum Temperature: 400°C
Manufacturing Standard: EN 10217-7
Dimensional Tolerance: ±0.05 mm
Brand: ARE-Applied Research
Resources
Important Notes
Designed for HPLC and high-pressure laboratory applications
Welded and annealed stainless steel construction
Large-bore tubing supports high flow rates and larger fluid volumes
Manufactured from corrosion-resistant 316L stainless steel
Maximum pressure rating of 21,000 psi
Maximum operating temperature of 400°C
Precision dimensional tolerances of ±0.05 mm
Suitable for preparative and process-scale chromatography systems
