Tubing, Stainless Steel, 0.083 inch (2.10 mm) ID, 1/8 (3.20 mm) OD, HPLC grade, 3 meter roll, ARE-Applied Research brand. 1 EA.
Additional Information:
ARE-Applied Research HPLC Grade Stainless Steel tubing is manufactured from high-purity 316L stainless steel and is designed for demanding high-pressure liquid chromatography applications. Welded and annealed for consistent performance, this tubing is manufactured and tested according to EN 10217-7 standards, providing the strength, dimensional accuracy, and reliability required for modern analytical laboratories.
49408-COIL-3M is supplied as a 3-meter continuous length with a 0.083 inch (2.10 mm) internal diameter and a 1/8 inch (3.20 mm) outer diameter. The large internal diameter is well suited for applications requiring higher flow rates, greater fluid volumes, and minimal flow restriction. This tubing is ideal for preparative chromatography systems, solvent delivery applications, bulk fluid transfer, and other high-flow laboratory processes where both durability and pressure resistance are essential.
The corrosion-resistant 316L stainless steel construction provides excellent compatibility with a wide range of solvents and chromatography mobile phases while delivering exceptional mechanical strength. With a maximum pressure rating of 24,000 psi (1654 bar) and a maximum operating temperature of 400°C, this tubing is suitable for demanding high-pressure laboratory environments and advanced chromatography systems.
Key Benefits
HPLC-grade 316L stainless steel construction
Manufactured and tested to EN 10217-7 standards
Large internal diameter for high-flow applications
Maximum pressure rating of 24,000 psi (1654 bar)
Excellent corrosion resistance
Suitable for preparative and process-scale fluid pathways
High temperature resistance up to 400°C
Durable welded and annealed construction
Typical Applications
Preparative HPLC systems
High-flow fluid transfer
Solvent delivery systems
Bulk mobile phase transport
Process chromatography
Analytical instrumentation
Laboratory fluid handling
Custom high-pressure fluid paths
Specifications
Product Type: Stainless Steel Tubing
Material: 316L Stainless Steel
Internal Diameter: 0.083 in. (2.10 mm)
Outer Diameter: 1/8 in. (3.20 mm)
Length: 3 Meters
Configuration: Continuous Length
Maximum Pressure: 24,000 psi (1654 bar)
Maximum Temperature: 400°C
Manufacturing Standard: EN 10217-7
Dimensional Tolerance: ±0.05 mm
Brand: ARE-Applied Research
Resources
Important Notes
Designed for HPLC and high-pressure laboratory applications
Welded and annealed stainless steel construction
Large-bore tubing supports high flow rates
Manufactured from corrosion-resistant 316L stainless steel
Maximum pressure rating of 24,000 psi
Maximum operating temperature of 400°C
Precision dimensional tolerances of ±0.05 mm
Suitable for preparative and process-scale chromatography systems
