Tubing, Stainless Steel, 0.010 inch (0.25 mm) ID, 1/32 inch (0.79 mm) OD, HPLC grade, 10 meter roll, ARE-Applied Research brand. 1 EA.
Additional Information:
ARE-Applied Research HPLC Grade Stainless Steel tubing is manufactured from high-purity 316L stainless steel and is designed for demanding high-pressure liquid chromatography applications. Welded and annealed for consistent performance, this tubing is manufactured and tested according to EN 10217-7 standards, providing the strength, dimensional accuracy, and reliability required for modern analytical laboratories.
49401-COIL-10M is supplied as a 10-meter continuous coil with a 0.010 inch (0.25 mm) internal diameter and a 1/32 inch (0.79 mm) outer diameter. The narrow internal diameter is ideal for minimizing system volume and maintaining chromatographic efficiency in HPLC and UHPLC fluid pathways. The tubing is suitable for constructing custom flow paths, replacing damaged tubing, or building specialized analytical configurations requiring precise fluid control.
The corrosion-resistant 316L stainless steel construction provides excellent compatibility with a wide range of HPLC mobile phases while offering outstanding mechanical strength and temperature stability up to 400°C. Its precision dimensions help ensure consistent flow characteristics and reproducible chromatographic performance.
Key Benefits
HPLC-grade 316L stainless steel construction
Manufactured and tested to EN 10217-7 standards
High-pressure capability for chromatography applications
Low internal volume design
Excellent corrosion resistance
Suitable for custom fluid pathways
High temperature resistance up to 400°C
Durable welded and annealed construction
Typical Applications
HPLC systems
UHPLC systems
High-pressure fluid transfer
Analytical instrumentation
Custom chromatography configurations
Sample delivery lines
Detector connections
Laboratory fluid pathways
Specifications
Product Type: Stainless Steel Tubing
Material: 316L Stainless Steel
Internal Diameter: 0.010 in. (0.25 mm)
Outer Diameter: 1/32 in. (0.79 mm)
Length: 10 Meters
Configuration: Continuous Coil
Maximum Temperature: 400°C
Manufacturing Standard: EN 10217-7
Dimensional Tolerance: ±0.05 mm
Brand: ARE-Applied Research
Resources
Important Notes
Designed for HPLC and high-pressure laboratory applications
Welded and annealed stainless steel construction
Manufactured from corrosion-resistant 316L stainless steel
Narrow internal diameter helps minimize system volume
Suitable for custom fluid path construction
Maximum operating temperature of 400°C
Precision dimensional tolerances of ±0.05 mm
