Column Inline Filter, for HPLC columns, replaceable filters and All-PEEK holder. Includes 25 disposable 2 um Ti filters. ARE-Applied Research brand. 5/PK.
Additional Info:
The 49680‑02S‑005 Inline Column Filter System is an economical, reusable column‑protection solution for analytical HPLC workflows that require reliable particulate removal without recurring replacement of the entire filter housing. This system combines a durable all‑PEEK holder with replaceable PEEK‑encased titanium filter discs, providing long‑term value and reduced consumable waste.
Designed for typical analytical HPLC flow rates, the system supports columns operating up to 4,500 psi and 5 mL/min. It is not recommended for UHPLC pressure ranges. The supplied 2.0 µm filter porosity offers effective particulate protection while minimizing added flow restriction, making it ideal for routine methods and cleaner sample matrices.
The reusable holder allows quick filter replacement when system backpressure increases—simply disconnect, replace the filter disc, and resume operation. No specialized tools are required.
Key Features
Reusable All‑PEEK Inline Filter Holder
Long‑life PEEK holder reduces disposable hardware cost
Chemically inert and corrosion‑resistant
Designed for repeated use in routine HPLC environments
Replaceable 2.0 µm Titanium Filters
Includes 25 PEEK‑encased titanium filter discs
Effective particle retention with low pressure impact
Suitable for routine analytical HPLC protection
Bio‑Inert Construction
PEEK and titanium materials
Minimizes interaction with sensitive analytes
Suitable for bioanalytical and purity‑critical workflows
Universal HPLC Compatibility
Fits all standard HPLC column threads and pilot lengths
Hand‑tightened or wrench‑tightened installation
Easily added to existing systems
Instrument & Column Protection
Installed after the pump, before the injector
Helps protect injectors, frits, and analytical columns
Extends column lifetime and improves method robustness
Usage & Replacement Guidance
Monitor system backpressure during operation. A gradual pressure increase typically indicates filter loading.
To replace a filter disc:
Reduce system pressure to atmospheric
Disconnect the inline filter holder
Remove and discard the used filter disc
Insert a new filter disc and reconnect
The system accepts any PEEK‑encased filter disc measuring ¼ inch OD × 1⁄16 inch thick, allowing flexibility in porosity selection.
Pressure Rating & Compatibility
Maximum pressure: 4,500 psi
Maximum recommended flow rate: 5 mL/min
Compatible with: Analytical HPLC systems
Not recommended for: UHPLC pressure ranges
An economical 10‑pack option is also available for higher‑volume labs.
Typical Applications
Routine analytical HPLC
Injector and column protection
Method development and validation
Cost‑controlled laboratory environments
Bio‑inert chromatography workflows
