Catalog Number - 49210-10-3M

49210-10-3M ARE‑Applied Research PTFE Tubing is a high‑purity, low‑pressure fluid transfer solution designed for HPLC, UHPLC, LC‑MS, and general laboratory applications, offering increased internal diameter for improved flow capacity along with excellent chemical resistance and dimensional stability.

Manufactured from virgin PTFE resin, this tubing contains no plasticizers or additives, ensuring minimal contamination risk and suitability for sensitive analytical workflows.

Precision Dimensions – Increased Flow Optimization

• Inner Diameter (ID): 0.010" (0.25 mm)

• Outer Diameter (OD): 1/16" (1.6 mm)

• Wall Thickness: 0.675 mm

• Tolerance (ID & OD): ± 0.10 mm

✅ Larger ID compared to 0.007" tubing for higher flow rates and reduced flow restriction

Low‑Pressure Chromatography Performance

• Designed for low‑pressure fluid paths, including:

  • Pre‑pump mobile phase delivery

  • Post‑detector waste lines

  • General solvent transfer

• Pressure Rating: 800 psi (55.2 bar)

✅ Ideal for applications requiring increased flow capacity with stable performance

Virgin PTFE Construction – High Purity & Inertness

• Made from 100% virgin PTFE

• No additives (except trace color coding particles)

• Chemically inert and non‑reactive

✅ Minimizes contamination in LC‑MS and high‑sensitivity methods

Broad Chemical & Thermal Resistance

• Resistant to:

  • Organic solvents

  • Acids and bases

  • Aqueous mobile phases

• Maximum Temperature: 260 °C

✅ Suitable for demanding analytical environments

Micro‑Porous Structure – Application Consideration

• PTFE tubing contains micropores allowing slight gas exchange

• Important consideration for:

  • Degassed solvents

  • Oxygen‑sensitive applications

✅ Consider alternative tubing when gas impermeability is critical

Flexible & Durable Design

• Flexible for easy routing and installation

• Durable under routine lab use

• Natural translucent color allows visual flow confirmation

✅ Supports efficient system setup and maintenance

Regulatory Compliance

• Compliant with:

  • RoHS EU Directive 2011/65/EU

  • Amendment (EU) 2015/863

✅ Meets global environmental and safety standards

Available Length Options

✅ Choose the length that best fits your application:

• 3 meter roll (this item)

• 1 meter roll

• 5 meter roll

• 10 meter roll

• 25 meter roll

✅ Custom cut lengths available through Customer Service

Typical Applications

• HPLC mobile phase delivery (pre‑pump)

• Solvent waste systems

• Low‑pressure fluid routing

• Laboratory solvent transfer

• OEM and instrument integration

Important Usage Notes

• Not intended for high‑pressure HPLC pump connections

• Consider permeability for degassed or oxygen‑sensitive solvents

• Ensure proper fittings for secure connections
