Catalog Number - 49210-10-10M

49210-10-10M ARE‑Applied Research PTFE Tubing is a high‑purity, low‑pressure fluid transfer solution engineered for HPLC, UHPLC, LC‑MS, and general laboratory applications, delivering increased internal diameter for improved flow capacity along with extended length for flexible system design.

Manufactured from virgin PTFE resin, this tubing contains no additives or plasticizers, ensuring minimal contamination risk and compatibility with sensitive analytical methods.

Precision Dimensions – Optimized for Higher Flow

• Inner Diameter (ID): 0.010" (0.25 mm)

• Outer Diameter (OD): 1/16" (1.6 mm)

• Wall Thickness: 0.675 mm

• Tolerance (ID & OD): ± 0.10 mm

✅ Larger ID than 0.007" tubing supports higher flow rates and reduced resistance

Low‑Pressure Chromatography Performance

• Designed for low‑pressure applications, including:

  • Pre‑pump mobile phase delivery

  • Post‑detector waste lines

  • General solvent transfer

• Pressure Rating: 800 psi (55.2 bar)

✅ Ideal for long‑distance solvent routing with stable performance

Virgin PTFE Construction – High Purity & Inertness

• Manufactured from 100% virgin PTFE

• No additives (except minimal color coding particles)

• Chemically inert and non‑reactive

✅ Minimizes contamination in LC‑MS and trace‑level analyses

Broad Chemical & Thermal Resistance

• Resistant to:

  • Organic solvents

  • Acids and bases

  • Aqueous mobile phases

• Maximum Temperature: 260 °C

✅ Suitable for demanding and long‑duration laboratory use

Micro‑Porous Structure – Application Consideration

• PTFE tubing contains micropores allowing slight gas exchange

• May impact:

  • Degassed solvents

  • Oxygen‑sensitive workflows

✅ Consider alternatives when gas impermeability is critical

Flexible & Durable Design

• Flexible for extended routing and system integration

• Durable for repeated use

• Natural translucent color allows visual confirmation of flow

✅ Supports efficient installation and long tubing runs

Regulatory Compliance

• Compliant with:

  • RoHS EU Directive 2011/65/EU

  • Amendment (EU) 2015/863

✅ Meets global environmental and safety standards

Available Length Options

✅ Choose the appropriate length for your system:

• 10 meter roll (this item)

• 1 meter roll

• 3 meter roll

• 5 meter roll

• 25 meter roll

✅ Custom cut lengths available through Customer Service

Typical Applications

• Extended HPLC mobile phase delivery (pre‑pump)

• Long solvent waste line routing

• Low‑pressure fluid transfer systems

• Laboratory solvent handling

• OEM and instrument integration

Important Usage Notes

• Not intended for high‑pressure pump head connections

• Consider permeability when using degassed or oxygen‑sensitive solvents

• Ensure proper fittings for leak‑free connections
