CUSTOM ITEM: Tubing Cutter, Wheel Type. For stainless steel tubing. Black. ARE-Applied Research brand. Bulk Price.
Additional Info:
The 46001‑01 Wheel‑Type Tubing Cutter is designed for controlled cutting of stainless steel tubing used in chromatography systems. Unlike polymer tubing, stainless steel tubing requires a different cutting approach to avoid collapsing the internal diameter, which can negatively impact system performance.
This cutter uses a scoring method, where the cutting wheel gradually scores the tubing circumference rather than cutting completely through. Once properly scored, the tubing is cleanly snapped, preserving the internal bore and maintaining flow integrity.
This tool is suitable for tubing with outer diameters ranging from 1/32" (0.8 mm) to 1/4" (6.4 mm) and features a precision cutting wheel (0.36 mm thickness) for controlled scoring.
While this cutter produces a usable cut for general or non‑critical applications, it is not recommended for critical HPLC connections, where perfect perpendicularity and zero deformation are required. For high‑performance applications, ECM‑cut pre‑cut stainless steel tubing is strongly recommended.
After cutting, it is important to finish the tubing end using a file to remove burrs and ensure proper sealing in fittings.
Why Use a Wheel‑Type Tubing Cutter?
Cutting stainless steel tubing improperly can cause:
Collapse or narrowing of the internal diameter
Flow restriction and increased backpressure
Poor sealing and leaks
Compromised chromatographic performance
The wheel‑type scoring method ensures:
Preserved internal diameter
Cleaner break compared to direct cutting
Reduced tubing deformation
Better connection reliability
Key Features
Designed for Stainless Steel Tubing
Suitable for metal tubing used in chromatography systems
Handles a wide OD range from 0.8 mm to 6.4 mm
Controlled Scoring Method
Scores tubing rather than cutting through completely
Allows clean break while preserving internal bore
Reduces risk of deformation and blockage
Precision Cutting Wheel
0.36 mm thickness wheel for consistent scoring
Maintains performance when kept clean and sharp
Supports Non‑Critical Connections
Produces acceptable cuts for routine applications
Ideal for general lab work and maintenance
Maintenance‑Ready Design
Cutting performance depends on wheel condition
Replaceable wheels extend tool lifespan
Requires post‑cut finishing for best results
Important Usage Notes
Not intended for critical HPLC connections
For high‑precision needs, use ECM‑cut pre‑cut tubing
Always file and clean tubing ends after cutting
Maintain cutting wheel cleanliness for optimal results
Typical Applications
Cutting stainless steel HPLC tubing
General fluidic system setup and maintenance
Non‑critical chromatography connections
Laboratory tubing preparation
Service and repair operations
Made‑to‑Order & Pricing Information
This is a custom, made‑to‑order item.
Orders cannot be canceled once placed
Custom items are non‑returnable
